Emulsion line marking trolley

Line painting trolley

- The trolley has 3 metal/rubber wheels and a sturdy metal frame to ensure stability during application.
- Paint is applied under pressure from a tank onto the intended surface.
- The sprayer tip is also the width adjustment of the paint stream, while the paddles at the bottom of the trolley are the width adjustment of the pitch lines.
- This method produces clear ("sharp") lines and ensures uniformity of the lines. This method produces clear ("sharp") lines and ensures line uniformity.
- Wet painting means increased line durability and weather resistance.
- Adjustable line width from 5 to 15 cm,
- Comfortable arm for easy guidance,
- Tank capacity 11.0 dm3.
- Total tank capacity 11.66 dm3.
- Average liquid flow rate 0.3-1.50 litres/min.
- Maximum operating pressure 0.4 MPa.
- Weight 2.3 kg.

Dimensions when folded:
- height - 95 cm,
- width - 85 cm,
- length - 115 cm

ATTENTION: after each painting, rinse well the pressure tank and the lines supplying emulsion to the paint nozzle.
ATTENTION: paint should be diluted with water at a ratio of 1:9. Thicker paint may cause clogging of the nozzle.

Product code: 100203
